Yamaha - RX-V481

This 5.1-channel 4K Ultra HD network AV receiver offers built-in Wi-Fi®, Bluetooth® and AirPlay® wireless connectivity, and supports playback of high-resolution audio files.

5.1 Ch, 115W per Ch

Description
- This 5.1-channel 4K Ultra HD network AV receiver offers built-in Wi-Fi®, Bluetooth® and AirPlay® wireless connectivity, and supports playback of high-resolution audio files. The free MusicCast Controller app makes it easy to access your music library and streaming music services. Add audio in up to 9 additional rooms with MusicCast wireless speakers or other MusicCast devices.

Specification

		RX-V481
AV Receiver
Amplifier Section	Channel	5.1
	Rated Output Power (1kHz, 1ch driven)	115 W (6 ohms, 0.9% THD)
	Rated Output Power (20Hz-20kHz, 2ch driven)	80 W (6 ohms, 0.09% THD)
	Maximum Effective Output Power (1kHz, 1ch driven) (JEITA)	145 W (6 ohms, 10% THD)
	Dynamic Power per Channel (8/6/4/2 ohms)	- / 110 / 130 / 160 W
Surround Sound Processing	CINEMA DSP	Yes (3D)
	DSP Programs	17
	Dialog Level Adjustment	Yes
	Virtual Presence Speaker	Yes
	Dialogue Lift	Yes
	SILENT CINEMA / Virtual CINEMA DSP	Yes (Virtual CINEMA FRONT)
	Dolby TrueHD	Yes
	Dolby Digital Plus	Yes
	DTS-HD Master Audio	Yes
Audio Features	Compressed Music Enhancer	Yes (incl. enhancer for Bluetooth)
	YPAO sound optimization	Yes
	Adaptive DRC (Dynamic Range Control)	Yes
	Initial Volume & Maximum Volume Setting	Yes
	Bi-amp capability	Yes
	Audio Delay	Yes (0-500 ms)
	192kHz/24-bit DACs for all channels	Yes (Burr-Brown)
Video Features	4K Ultra HD Pass-through	Yes (4K 60p 4:4:4)
	HDMI 3D passthrough	Yes
	HDMI Audio Return Channel	Yes
	Deep Color/x.v.Color/24Hz Refresh Rate /Auto Lip-Sync	Yes
Connectivity	HDMI Input/Output	4 / 1 (HDCP2.2, HDR and BT.2020 compatible)
	HDMI CEC	Yes
	USB Input	USB Memory, Portable Audio Player
	Network Port	Yes
	Wi-Fi	Yes (with Wireless Direct)
	AirPlay	Yes
	Bluetooth	Yes (SBC / AAC)
	Front AV Input	USB / Mini Jack
	Digital Audio Input/Output: Optical	1 / 0
	Digital Audio Input/Output: Coaxial	2 / 0
	Analog Audio Input/Output	4 (front 1) / 0
	Composite Video Input/Output	4 / 1
	Preout	Subwoofer
	Headphone Output	1
Tuner Section	FM/AM Tuner	Yes
User Interface	On-screen display	Yes (colour OSD)
	SCENE	SCENE (4 sets)
	App Control	Yes (iPhone / iPad / Android phone / tablet)
	Remote Control Unit	Yes
Zone Control	Zone B Output	Yes
General	Standby Power Consumption (IR only)	≤0.1W
	Auto Power Standby	Yes
	ECO mode	Yes
	Dimensions (W x H x D)	435 x 161 x 327 mm (with antenna: 435 x 225.5 x 327 mm); 17-1/8” x 6-3/8” x 12-7/8” (with antenna: 17-1/8” x 8-7/8" x 12-7/8”)
	Weight	8.1 kg; 17.9 lbs.
